NavSource Online: Submarine Photo Archive

O-13 (SS-74)

Radio Call Sign: November - Echo - Zulu - November
O-11 Class Submarine: Laid down, 6 March 1916, at Lake Torpedo Boat Co., Bridgeport, CT.; Launched, 27 December 1917; Commissioned, USS O-13, 27 November 1918, at New York; Designated (SS-74), 17 July 1920; Decommissioned, 11 June 1924, at Philadelphia, PA.; Laid up in the Atlantic Reserve Fleet, Philadelphia; Struck from the Naval Register, 9 May 1930; Final Disposition, sold for scrapping, 30 July 1930

Specifications: Displacement, surfaced: 491 t., submerged: 566 t.; Length 175'; Beam 16' 7"; Draft 13' 11"; Speed, surfaced 14 kts, submerged 11 kts; Operational Depth Limit 200 ft; Complement 2 Officers 27 Enlisted; Armament, four 18" torpedo tubes, eight torpedoes, one 3"/23 deck gun; Propulsion, diesel-electric, Busch Sulzer Brothers Diesel Engine Co., diesels, 1,000 hp, Fuel Capacity, 18,588 gal.; Diehl Manufacture Co. electric motors, 800 hp, Battery Cells 120, single propeller.
Click On Image
For Full Size		Size Image Description Source
O-13 181k Starboard view of the O-13 (SS-74) in 1918 with crew in dress whites lined up on deck, probably a Tiger Cruise or something like it. Sub School? There are close to 60 men on deck, way above crew size.
Prior to her commissioning, O-13 rammed and sank Mary Alice, a section patrol boat accompanying the recently completed submarine during her submerged trials in Long Island Sound, 5 October 1918. O-13 struck and holed the patrol ship amidships; although Mary Alice sank with minutes, O-13 rescued her crew.
It is highly unlikely that the sailors on board the deck of O-13 in this photo are from the Mary Alice, but it gives you an idea of how 60 plus men fit on her small deck. 		Text courtesy of DANFS & Ric Hedman. USN photo courtesy of ussubvetsofwwii.org.
O-13 & 14 235k O-13 (SS-74) & O-14 (SS-75) in Panama Canal, either 1920 when they arrived in CZ, or 1923 on their way back to the Atlantic. Photo courtesy of CDR John Joseph Hughes' collection via David Wright.
Coco Solo1.66kUS Sub Base, Coco Solo, Panama Canal Zone: 26 September 1922.
France Field is in the background.
One of the Henry Ford built Eagle class patrol boats is in the lower left corner of the basin.
Identifiable submarines are not clear enough for positive ID’s, but all the 6 Lake Torpedo Boat Co. O-class boats: O-11 (SS-72), O-12 (SS-73), O-13 (SS-74), O-14 (SS-75), O-15 (SS-76) & O-16 (SS-77) were assigned there for the bulk of their active service before being scrapped in 1930.		Photo i.d. courtesy of Ric Hedman & David Johnston.
Record Group 18: Records of the Army Air Forces, ca. 1902 - 1964
Series: "Airscapes" of American and Foreign Areas, 1917 - 1964
File Unit: Panama Canal Zone - Coco Solo
Local Identifier: 18-AA-108-33
National Archives Identifier: 68147899
Photo courtesy of catalog.archives.gov
SS 73 421k Three O boats docked from left to right in the 1920's. O-15 (SS-76) might be on the left, the middle boat is O-13 (SS-74), & O-16 (SS-77) Photo i.d. courtesy of David Johnston
Photo courtesy Tommy Trampp.
O-11 through O-16 238k From inboard to outboard: O-11 (SS-72), O-13 (SS-74), O-14 (SS-75), O-15 (SS-76), O-16 (SS-77) and O-12 (SS-73), at the Washington D.C. Navy Yard, circa 1918-24. USN photo # 80-G-1024950, from the National Archives and Records Administration (NARA), courtesy of Daniel Dunham.
Charles B. Momsen 60k Charles B. Momsen, USN. Following submarine training at the Naval Submarine Base, New London, Connecticut, he reported in January 1922 as Executive Officer of the submarine O-13 (SS-74), based at Coco Solo in the Panama Canal Zone.
He appears here as a Lieutenant Commander in a Photograph taken 1 September 1934. 		Text courtesy of history.navy.mil.
USNHC photograph NH 47733, Collection of Vice Admiral Charles A. Lockwood, 1967.
O-11 through O-16 81k O boats possibly in Phila. PA circa 1924:
From inboard to outboard: unidentified O boat, [probably O-13 (SS-74) or O-15 (SS-76)] O-11 (SS-72), O-12 (SS-73), O-16 (SS-77) & O-14 (SS-75). 		USN photo submitted by Charles Worcester.
O-16
0807700		674kPhiladelphia in the late 1920’s.
From left to right: Two K-class: (No definite i.d. which ones of the following 8 ): K-1 (SS-32), K-2 (SS-33), K-3 (SS-34), K-4 (SS-35), K-5 (SS-36), K-6 (SS-37), K-7 (SS-38), K-8 (SS-39).
Four EB design L-class (No definite i.d. which ones of the following 4 ): L-2 (SS-41), L-3 (SS-42), L-9 (SS-49) & L-11 (SS-51).
Two Lake design O-class (No definite i.d. which ones of the first 4): O-11 (SS-72), O-13 (SS-74), O-14 (SS-75), O-15 (SS-76 ), with the last boat being O-16 (SS-77) on far right.
All boats are in various states of disrepair, and all would be disposed of by scrapping by the summer of 1930 in accordance with the London Naval Treaty. 		Photo courtesy of David Wright.
Text i.d. via David Johnston.
View the O-13 (SS-74)
DANFS history entry located on the Haze Gray & Underway Web Site.
Crew Contact And Reunion Information
Not Applicable to this Vessel
