Click On Image
For Full Size Image | Size |
Image Description |
Source |
 |
41k |
Trumpetfish (SS-425), circa 1947 after her first GUPPY conversion.
|
US Navy photo. |
 |
10k |
Trumpetfish (SS-425), circa 1947 after her first GUPPY conversion. |
Courtesy of George M. Arnold. |
 |
201k |
Amberjack (SS-522) on the left and Trumpetfish (SS-425), tied up to the pier at Pensacola, Florida., circa 1948. |
Photo courtesy of Jim Carroll and submitted by Mike Keating. |
 |
127k |
Amberjack (SS-522) outboard of Trumpetfish (SS-425), tied up to the pier at Pensacola, Florida., circa 1948. |
Photo courtesy of Jim Carroll and submitted by Mike Keating. |
 |
141k |
The following five photos are a series showing the FRAM conversion that was accomplished at the
Charleston S.C. Navy Yard in 1961 The first is the stern portion of the Trumpetfish (SS-425), cut open and ready to receive her new plug at her FRAM conversion This conversion added 18 feet to the length of the sub. |
USN photo courtesy of Robert Hall. |
 |
32k |
Forming new hull sections for the Trumpetfish (SS-425), at her FRAM conversion. |
USN photo courtesy of Robert Hall. |
 |
53k |
Being offloaded from a flatbed truck, a crane swings the new hull section for the Trumpetfish (SS-425), into position. |
USN photo courtesy of Robert Hall. |
 |
63k |
A crane swings the new hull section for the Trumpetfish (SS-425), into position between her two seperated sections. |
USN photo courtesy of Robert Hall. |
 |
61k |
With a little room to spare, the new hull section for the Trumpetfish (SS-425) is into position between her two seperated sections. |
USN photo courtesy of Robert Hall. |
 |
45k |
1961 Hull configuration of the Trumpetfish (SS-425) as a GUPPY III. 18 feet was added to the after battery and the PUFF sonar was added. Sonar was moved to Control Room. North Atlantic Sail was added at this time also. She appeared in this configuration until she was decommissioned in 1973.
|
Courtesy of George M. Arnold. Text courtesy of usstrumpetfish.com |
 |
154k |
Trumpetfish (SS-425) while in Malta in 1969. The destroyer Gearing (DD-710) is off her starboard bow. |
USN photo courtesy of Richard J. Pasco, former TM2 (SS). |
 |
18k |
Commemorative post mark on the occasion of Trumpetfish's (SS-425) visit to Port Everglades, Florida on 16 June 1973. |
Courtesy of Jack Treutle. Photo added 12/06/06. |
 |
29k |
The ex-Trumpetfish (SS-425) as the Brazilian Goiaz (S-15) entering the drydock DFlt Afonso Pena - G 25 in 1985. |
Brazilian Navy photo by Mario Roberto Vaz Carneiro & segurancaedefesa.com, courtesy of naviosdeguerrabrasileiros.hpg.ig.com.br, & submitted by Valdo Novaes. |
 |
22k |
The ex-Trumpetfish (SS-425) as the Brazilian Goiaz (S-15) entering the Bay of Guanabara, at Rio de Janeiro, Brazil. |
Brazilian Navy photo by Mario Roberto Vaz Carneiro & segurancaedefesa.com, courtesy of naviosdeguerrabrasileiros.hpg.ig.com.br, & submitted by Valdo Novaes. |
 |
56k |
Drills in the Torpedo room of the ex-Trumpetfish (SS-425) as the Brazilian Goiaz (S-15). |
Brazilian Navy photo by SDM, courtesy of naviosdeguerrabrasileiros.hpg.ig.com.br, & submitted by Valdo Novaes. |
 |
42k |
The commander of the the ex-Trumpetfish (SS-425) as the Brazilian Goiaz (S-15) checks his bearings. |
Brazilian Navy photo by SDM, courtesy of naviosdeguerrabrasileiros.hpg.ig.com.br, & submitted by Valdo Novaes. |
