NavSource Online: Amphibious Photo Archive

LSM-217


Awards, Citations and Campaign Ribbons


Precedence of awards is from top to bottom, left to right
Top Row - American Campaign Medal - Asiatic-Pacific Campaign Medal (1)
Bottom Row - World War II Victory Medal - Navy Occupation Service Medal (with Asia clasp) - Philippine Liberation Medal (1)


LSM-1 Class Landing Ship Medium:
  • Laid down (date unknown) at Dravo Corporation, Wilmington, DE.
  • Launched (date unknown)
  • Commissioned USS LSM-217, 4 August 1944, LT. Eugene J. Heisley, USNR, in command
  • During WWII LSM-217 was assigned to the Asiatic-Pacific Theater and participated in the:
  • Decommissioned, 2 May 1946
  • Struck from the Naval Register in 1946
  • Final Disposition, sold, 22 October 1947, to Avondale Marine Ways, Inc., Westwego, LA., fate unknown
  • LSM-217 earned one battle star for World War II service
    Specifications:
    Displacement 520 t.(light), 743 t. (landing) 1,095 t.(fully loaded)
    Length 203' 6"
    Beam 34' 6"
    Draft light, 3' 6" forward, 7' 8" aft, fully loaded, 6' 4" forward, 8' 3" aft
    Speed 13.2 kts. (max.), (928 tons displacement)
    Complement 5 officers, 54 enlisted
    Armament one single bow mounted 40mm gun, four single 20mm gun mounts
    Vehicle/Boat Capacity 5 medium or 3 heavy tanks, or 6 LVT's, or 9 DUKW's
    Troop Capacity 2 officers, 46 enlisted
    Armor 10-lb. STS splinter shield to gun mounts, pilot house and conning station
    Propulsion two Fairbanks Morse (model 38D81/8X10, reversible with hydraulic clutch) diesels. Direct drive with 1,440 BHP each @ 720rpm, twin screws, Endurance, 4,900 miles @ 12kts.(928 tons displacement)

    Click On Image
    For Full Size Image
    Size Image Description Contributed
    By
    LSM-217 56k Launching of LSM-217 at Dravo Shipbuilding Co, Wilmington DL. USS LSM / LSMR Association
    LCM-217 49k LSM-217 in convoy from Manila to Japan about 26 September 1945. Ralph E. Robinson USS LSM-34
    Culebra Island 78k LSM-217 alongside Culebra Island (ARG-7). The outboard LSM is unidentified, date and place unknown. Photo by Vincent Cottrell Daniel Cottrell in honor of his father Vincent Cottrell, Coxswain, USNR USS Culebra Island

    The DANFS history extract for LSM-217 is from LSM-LSMR Amphibious Forces, Vol. II. Paducah, Kentucky: Turner Publishing Company, © 1997. (ISBN 1-56311-389-9).
