NavSource Online: Submarine Photo Archive
Contributed by Mike Smolinski
Henry M. Jackson (SSBN-730)
Please report any broken links or trouble you might come across to the Webmaster.
Please take a moment to let us know so that we can correct any problems and make your visit as enjoyable and as informative as possible.
| Click On Image For Full Size | Size | Image Description | Source By |
|
|---|---|---|---|---|
 | 63k | Cut out of the Ohio Class (SSBN-743) submarine. | Courtesy of Robert Hall. | |
 | 83k | Sponsor Sheila McKinney Watkins is escorted by David S. Lewis, Chairman of the Board at General Dynamics, as they depart after the launching ceremony for the nuclear-powered strategic missile submarine Georgia (SSBN-729). Walking behind her are Admiral James D. Watkins, Chief of Naval Operations, and Maid of Honor Susan Watkins on 6 Nov 1982. Behind it, under construction, is the Rhode Island (SSBN-730). The boat's name was changed to Henry M. Jackson (SSBN-730) in honor of the late senator who died 1 September 1983, she would be launched on 15 October 1983. | USN photo # DN-ST-83-04507 by PH2 Dana Babin & text from the Department of Defense Still Media Collection, courtesy of dodmedia.osd.mil. & submitted by Bill Gonyo. | |
 | 718k | A view of the nuclear-powered strategic missile submarine Georgia (SSBN-729), during the launch ceremony 6 November 1982. Behind it, under construction, is the Rhode Island (SSBN-730). The boat's name was changed to Henry M. Jackson (SSBN-730) in honor of the late senator who died 1 September 1983, she would be launched on 15 October 1983. | USN photo # DN-ST-83-04518 by PH2 Dana Babin & text from the Department of Defense Still Media Collection, courtesy of dodmedia.osd.mil. | |
 | 249k | The Portsmouth (SSN-707) slides down the launching ways at Electric Boat Division, General Dynamics Corp., Groton, CT, 18 September 1982. The boomer in the background is the Rhode Island (SSBN-730). The boat's name was changed to Henry M. Jackson (SSBN-730) in honor of the late senator who died 1 September 1983, she would be launched on 15 October 1983. | USN photo courtesy of Dusty Wilson (MMCSS Ret.) with photo i.d. courtesy of Fabio Pena. | |
 | 57k | The Portsmouth (SSN-707) slides down the launching ways at Electric Boat Division, General Dynamics Corp., Groton, CT, 18 September 1982. The boomer in the background is the Rhode Island (SSBN-730) before her name was changed to Henry M. Jackson (SSBN-730) in honor of the late senator who died 1 September 1983, she would be launched on 15 October 1983. | USN photo courtesy of news.navy.mil. & submitted to this site by Bill Gonyo. photo i.d. courtesy of Dusty Wilson (MMCSS Ret.) | |
 | 83k | Launching Program for the Henry M. Jackson (SSBN-730), held at Electric Boat at Groton, CT on 15 October 1983. | Photo courtesy of Robert M. Cieri. | |
 0873023 |
1.97k | A petty officer 3rd class escorts Helen Jackson, wife of the late Senator Henry Jackson, to the speakers platform prior to the commissioning of the nuclear-powered strategic missile submarine Henry M. Jackson (SSBN-730). Anna Marie Jackson, sponsor, is in the foreground. | Local ID: 330-DN-SN-85-07363. Photo courtesy of catalog.archives.gov | |
 0873024 |
1.43k | Anna Marie Jackson, daughter of the late Sen. Henry M. Jackson, D-Washington, and sponsor of nuclear-powered strategic missile submarine Henry M. Jackson (SSBN-730), christens the ship with a bottle of champagne during the launching ceremony. | Local ID: 330-CFD-DN-SN-84-01951. Photo courtesy of catalog.archives.gov | |
 0873025 |
2.87k | Captain (CAPT) Michael A. Farmer, commanding officer (gold), holds up a bust of the late Senator Henry M. Jackson. The bust is being presented by Anna Marie Jackson, sponsor, at the reception following the commissioning of the nuclear Henry M. Jackson (SSBN-730). | Local ID: 330-CFD-DN-SN-85-07338. Photo courtesy of catalog.archives.gov | |
 0873026 |
1.35k | Attending the launching ceremony for the nuclear-powered strategic missile submarine Henry M. Jackson (SSBN-730) are, from left to right: the late Sen. Henry M. Jackson's children, Peter and Anna Marie; his widow, Helen Jackson; David S. Lewis and Fritz G. Tovar, both of General Dynamics Corp. | Local ID: 330-CFD-DN-SN-84-01945. Photo courtesy of catalog.archives.gov | |
 0873001 |
1.75k | Two crewmen raise the ensign aboard the nuclear-powered strategic missile submarine Henry M. Jackson (SSBN-730). | Local ID: 330-CFD-DN-SN-85-07372. Photo courtesy of catalog.archives.gov | |
 | 31k | Commemorative postal cover marking the launching of the Henry M. Jackson (SSBN-730), at the Electric Boat Division of General Dynamics, Groton, CT., 15 October 1983. | Courtesy of Jack Treutle (of blessed memory). | |
 | 140k | Crewmen raise the admiral's flag aboard the nuclear-powered strategic missile submarine Henry M. Jackson (SSBN-730) during its commissioning ceremony. Admiral Kinnaird R. McKee, Deputy Commander for Nuclear Propulsion, Naval Sea Systems Command, is a guest at the commissioning ceremony for the Ohio class nuclear-powered strategic missile submarine on 6 October 1984. | USN photo # DN-SC-85-08002 by PHAN Karen Boulden,nfrom the Department of Defense Still Media Collection, courtesy of dodmedia.osd.mil. & submitted by Bill Gonyo. | |
 | 146k | Starboard side view of the nuclear-powered strategic missile submarine Henry M. Jackson (SSBN-730) during its commissioning ceremony. | USN photo # DN-SN-85-07371 from the Department of Defense Still Media Collection, courtesy of dodmedia.osd.mil. & submitted by Bill Gonyo. | |
 | 267k | The 21st demonstration and shakedown operational launch of a Trident missile takes place from the nuclear-powered strategic missile submarine Henry M. Jackson (SSBN-730) on 4 December 1984. This is also the 46th flight of the Trident. | USN photo # DF-SC-85-12676 by Bob Duff, from the Department of Defense Still Media Collection, courtesy of dodmedia.osd.mil. & submitted by Bill Gonyo. | |
 | 397k | A low-angle bow view of the nuclear-powered strategic missile submarine Henry M. Jackson (SSBN-730) inside the Magnetic Silencing Facility, Bangor, WA., 1 May 1985. | USN photo by Linda Skonieczny, from the Department of Defense Still Media Collection, courtesy of dodmedia.osd.mil. & submitted by Bill Gonyo. | |
 0873016 |
2.28k | Aerial view of the Delta Pier. Three Trident submarines are visible, Henry M. Jackson (SSBN-730); Ohio (SSBN-726) (top) and Florida (SSBN-728) in the drydock, Bangor WA., 1 August 1985. | Local ID: 330-CFD-DN-SC-86-01941. Photo courtesy of catalog.archives.gov | |
 | 138k | The nuclear-powered strategic missile submarine Henry M. Jackson (SSBN-730), is serviced at Delta Pier on 1 June 1987. The Olympic moutain range is in the background. | USN photo # DN-ST-88-05575 by Brian Nokell, from the Department of Defense Still Media Collection, courtesy of dodmedia.osd.mil. & submitted by Bill Gonyo. | |
 | 148k | A port bow view of the nuclear-powered strategic missile submarine Henry M. Jackson (SSBN-730) moored to a pier at Pearl Harbor on 1 July 1989. | USN photo # DN-SC-92-06793 by OS2 john Bouvia & text from the Department of Defense Still Media Collection, courtesy of dodmedia.osd.mil. & submitted by Bill Gonyo. | |
 0873002 |
3.83k | The nuclear-powered strategic missile submarine Henry M. Jackson (SSBN-730) heads into Naval Station, Pearl Harbor, Hawaii, for a visit, 1 November 1989. | Local ID: 330-CFD-DN-SC-92-04486. Photo courtesy of catalog.archives.gov | |
 | 114k | In June 2001, CAPT Mark Olson took command of Henry M. Jackson (SSBN-730) (BLUE). During his tour, his crew completed five strategic deterrent patrols, earned three awards of the Medical 'M', two awards each of the Navigation 'N' and Communications 'C', one award of the Engineering 'E' and Deck 'S', and the Submarine Group Nine Command Excellence Award. | USN photo submitted by Bill Gonyo. | |
 | 91k | Night view of the Henry M. Jackson (SSBN-730), at the sub base at Bangor, WA., putting to sea on 4 January 2004, during the big Puget Sound snowstorm. | Contributed by Larry Lee, courtesy of rontini.com. | |
 | 133k | Commemorative postal cover marking the Henry M. Jackson (SSBN-730), undergoing D-5 conversion at Puget Sound Naval Base, 7 December 2004. | Courtesy of Jack Treutle (of blessed memory). | |
 | 124k | At left, Certified Executive Chef Klaus Schubauer of the Double Tree Hotel in Misosula, Mont., teaches Culinary Specialists from the Henry M. Jackson (SSBN-730) Gold Crew some new cooking ideas and techniques at the Trident Refit Dining Facility on 27 February 2005. | USN photo by John Woodmansee, text courtesy of JO2 Mary Popejoy, Subase Bangor Public Affairs, csp.navy.mil. | |
 | 58k | The nuclear-powered strategic missile submarine Henry M. Jackson (SSBN-730) transits the Panama Canal, circa 2005. | USN photo courtesy of the Panama Canal Company. | |
 | 225k | Crew members aboard the ballistic missile submarine Henry M. Jackson (SSBN-730), load fresh Hawaiian fruit after arriving in Pearl Harbor on 31 March 2008 after their first patrol in four years. | USN photo # N-6107B-003 by Sonar Technician 2nd Class Will Blackshear, courtesy of news.navy.mil. | |
 | 122k | Torpedoman's Mate 3rd Class Garrity Johnson stands lookout aboard the ballistic missile submarine Henry M. Jackson (SSBN-730) as she pulls out of Pearl Harbor, Hawaii. | USN photo # N-6107B-001 by Sonar Technician 2nd Class Will Blackshear, courtesy of news.navy.mil. | |
 | 302k | Sailors assigned to the ballistic-missile submarine Henry M. Jackson (SSBN-730) participate in firefighting training at the advanced firefighting school at Trident Training Facility, Bangor. | USN photo # N-4649C-001 by Mass Communication Specialist 2nd Class Chantel M. Clayton. via Bill Gonyo. | |
 | 221k | Machinist's Mate 1st Class Steven Perry, an instructor at the the advanced firefighting school at Trident Training Facility, Bangor at Naval Base Kitsap, ensures a Sailor stationed aboard the ballistic-missile submarine Henry M. Jackson (SSBN-730) is properly dressed in a firefighting ensemble before firefighter training at Silverdale, Wash. 10 September 2008. | USN photo # N-4649C-003 by Mass Communication Specialist 2nd Class Chantel M. Clayton. | |
 | 5.38k | The attached file gives about 50 photos and illustrations of a Trident missile submarine and its equipment. It gives you a pretty good idea of the surroundings and "living in a sewer pipe" with unclassified pictures. | Richard Scheeder via Ron Reeves (of blessed memory) | |
 | 473k | James Sketchley, president of the Everett Council of the Navy League, and Cmdr. Jeffrey Farah, Gold Crew commanding officer of the ballistic missile submarine Henry M. Jackson (SSBN-730) sign documents recognizing the adoption of the Henry M. Jackson by the Everett and Bremerton-Olympic Peninsula councils of the Navy League on 25 January 2012. | US Navy photo # 120125-N-GU530-067 USN photo by Lt. Ed Early, courtesy of news.navy.mil. | |
 |
1.23k | Facilitators watch as Sailors assigned to the ballistic missile submarines Nevada (SSBN-733) and Henry M. Jackson (SSBN-730) compete against each other during the Naval Base Kitsap damage control Olympics on 22 July 2016, facilitated by Commander, Submarine Group Nine and its tenant commands. The competition is held at commands throughout the Navy to test damage control, fire fighting and de-flooding, capabilities while building camaraderie and morale among shipmates. | US Navy photo # 160722-N-OO032-040 by Mass Communication Specialist 2nd Class Cory Asato, courtesy of news.navy.mil. | |
 0873022 |
2.42k | An unmanned aerial vehicle delivers a payload to the Henry M. Jackson (SSBN-730) while underway near the Hawaiian Islands, 19 October 2020. Underway replenishment sustains the fleet anywhere/anytime. | USN photo # 201019-N-KB401-1364 photo by Mass Communication Specialist 1st Class Michael B. Zingaro | |
 0873021 |
4.84k | U.S. Marine Corps Staff Sgt. Ruben Arzate, attached to the "Lucky Red Lions" of Marine Medium Tiltrotor Squadron (VMM) 363, lowers a payload from an MV-22B Osprey to the Henry M. Jackson (SSBN-730) in the vicinity of the Hawaiian Islands, 21 October 2020. Underway replenishment sustains the fleet anywhere/anytime. This event was designed to test and evaluate the tactics, techniques, and procedures of U.S. Strategic Command's expeditionary logistics and enhance the overall readiness of our strategic forces. | U.S. Marine Corps photo # 201021-M-RA909-1111 by Cpl. Matthew Kirk courtesy of navy.mil | |
