NavSource Online: Amphibious Photo Archive


Contributed by Don McGrogan BMCS USN (Ret.) Popular Patch

USS Fort Lauderdale (LPD-28)


San Antonio Class Amphibious Transport Dock:
  • Laid down, 13 October 2017, at Ingalls Shipbuilding, Pascagoula, MS.
  • Launched, 28 March 2020
    Specifications:
    Displacement 25,000 t.(fl)
    Length 684'
    Beam 105'
    Draft 23 ft.
    Speed 22 kts.
    Complement 33 Officers, 411 Enlisted
    Troop Accommodations 66 Officers, 625 Enlisted
    Mission Systems
    Vehicles/Cargo (Net): Three Vehicle Decks (2323 sq m)
    Two Cargo/Ammo Magazines (708 cu m)
    Cargo Fuel, JP-5 (1190 cu m) , MOGAS (38 cu m)
    Two LCACs
    Medical
    Two Operating Rooms
    24 Person Hospital Ward
    100 Casualty Overflow Capacity:
    Aviation Facilities
    Hangar - "O" Level, Maintenance Facilities for; One CH-53E, or Two CH-46s, or One MV-22, or Three UH/AH-1s
    Landing - Two CH-53s, or Four AH/UH-1s, or Four CH-46s, or Two MV-22s, or One AV-8B Harrier:
    Main Propulsion
    4 - Medium Speed Turbocharged Marine Diesels
    2 - Shafts
    2 - Single Reversing Reduction Gears
    2 - Inboard Rotating (top) Fixed Pitch Propellers
    Electric Plant
    5 - 2500 KW Ship Service Marine Diesel Generators
    5 - Main Ship Service 60 Hz SWBS
    3 - Ship Service 400 Hz SWBS
    3 - 60 to 400 Hz solid State Frequency changers
    Zonal 60 Hz Power distribution system
    Advanced Degaussing System
    Auxiliaries
    7 - 700 KW Non-CFC Air conditioning Plants
    5 - 12000 GPD Reverse Osmosis Desalination Plants
    10 - 1000 GPM Navy Standard Firepumps
    2 - HP Air Compressors
    3 - LP Air Compressors
    3 - Deballast Air Compressors
    Navigation
    Digital Flux Gate Magnetic Compass
    AN/WSN-7(V)1 Inertial Navigation System
    AN/WQN-2 Doppler Sonar Velocity Log System
    AN/UQN-4A Sonar Sounding Set, Dead Reckoning System
    Navigation Telex System
    AN/SSN-6 NAVSSI
    Armament
    1 - MK 41, 16 Cell VLS, (Space & Weight)
    2 - MK 31 Mod 0 RAM Launchers
    2 - MK 46 Mod 1 30mm Machine Guns
    2 - MK 26 Mod 17 .50 Cal Machine Guns
    Command & Control
    AN/SPQ-12(V) Radar Display Dist. Distribution System
    MK 2 SSDS
    AN/USQ-119C(V)27 JMCIS
    AN/KSQ-1 Amphibious Assault Direction System
    MK 91, 2 Channel MFCS
    AN/USG-2 CEC
    Radar Systems
    AN/SPS-48E
    AN/SPQ-9B
    AN/SPS-73
    EW & Decoy Systems
    AN/SLQ-25A NIXIE
    AN/SLQ-32Q(V)2
    MK 36 SRBOC
    MK 53 / NULKA

    Click On Image
    For Full Size Image
    Size Image Description Source
    Fort Lauderdale
    10092801
    75k Fort Lauderdale (LPD-28), launching 28 March 2020, at Ingalls Shipbuilding, Pascagoula, MS.

    USS Fort Lauderdale (LPD-28)

    Commanding Officers
    Courtesy Wolfgang Hechler

    Crew Contact And Reunion Information
    U.S. Navy Memorial Foundation - Navy Log

    Additional Resources and Web Sites of Interest
    Navy Fact File - Amphibious Transport Dock - LPD
    Federation of American Scientists, Military Analysis Network, US Navy Ships
    You Tube - HII Launches the Future USS Fort Lauderdale (LPD 28) for the U.S. Navy
