NavSource Online: Amphibious Photo Archive

USS St. Croix River (LSMR-524)
ex
USS LSM(R)-524 (1945 - 1955)


Awards, Citations and Campaign Ribbons

Precedence of awards is from left to right
American Campaign Medal - Asiatic-Pacific Campaign Medal - World War II Victory Medal


LSM(R)-501 Class Landing Ship Medium (Rocket):
  • Laid down, 5 May 1945, at Brown Ship Building Co, Houston, TX.
  • Launched, 9 June 1945
  • Commissioned USS LSMR-524, 14 August 1945, at Houston, TX., LT Stephen A. Humsjo, USNR in command
  • During World War II USS LSM(R)-524 was assigned to the Asiatic-Pacific Theater:
    LSM(R) Flotilla Eighteen, CAPT. C. F. Macklin USN
    LSM(R) Group Forty-Four
    LSM(R) Division One Hundred Eight
  • Decommissioned, 21 May 1946, at Green Cove Springs, FL.
  • Laid up in the Atlantic Reserve Fleet, Florida Group, Green Cove Springs
  • Named USS St. Croix River LSM(R)-524, 1 October 1955
  • Struck from the Naval Register, 1 October 1958
  • Final Disposition, sold in 1961, fate unknown
    LSM(R) Specifications:
    Displacement 758 t.(light), 993 t. (attack) 1,175 t. (fully loaded)
    Length 206' 3"
    Beam 34' 6"
    Draft light, 5' 4" (mean), attack 6' 9" (mean), fully loaded 7' 9" (mean)
    Speed 13 kts.
    Complement 6 officers, 137 enlisted
    Armament
    one single 5"/38 dual purpose gun mount
    two twin 40mm AA gun mounts
    four twin 20mm AA gun mounts
    ten twin continuous loading 5" SS rocket launchers
    four 4.2" mortars
    Armor 10-lb. STS on conning station, pilot-house, radio room, radar plot, and rocket control, 10-lb. ASPP around 40 and 20mm gun mounts and directors
    Endurance 3,000 miles @ 13kts
    Propulsion
    two General Motors 16-287A (non-reversing with airflex clutch) Diesel engines, direct drive with 1,440 BHP each @ 720rpm
    Ship's Service Generators
    four Diesel-drive 100Kw 450V A.C.
    two Diesel-drive 20Kw 120V D.C.
    twin screws 2,800 shp

    Click On Image
    For Full Size Image
    Size Image Description Contributed
    By
    LSMR-524 488k USS LSM(R)-524 Pre-commissioning crew at completion of training at US Atlantic Fleet Amphibious Base Little Creek Norfolk, VA. May 1945. Mark McDonald courtesy Vernice R. Thompson USS LSM(R)-524
    LSMR-524 427k USS LSM(R)-524 LT. Stephen A. Humsjo and ship's officers, date and location unknown.
    Photo by John A. McDonald USS LSMR-524.
    Mark McDonald for his father John A. McDonald S1/c (at right) USS LSM(R)-524
    LSMR-524 94k USS LSM(R)-524 commissioning ceremony at Southern Pacific Docks, Houston, TX. 14 August 1945. (Note: the twin 5 inch SS rocket launcher mounts have not yet been installed.) Mark McDonald for his father John A. McDonald S1/c USS LSM(R)-524
    LSMR-524 127k USS LSM(R)-524 commissioning ceremony at Southern Pacific Docks, Houston, TX. 14 August 1945. Mark McDonald for his father John A. McDonald S1/c USS LSM(R)-524
    LSMR-524 118k USS LSM(R)-524 under way in the Gulf of Texas during her shake down cruise, 20 September 1945. (Good view of ships armament - ten twin continuous loading 5" SS rocket launchers, two twin 40mm gun mounts, four twin 20mm gun mounts, four 4" 2 mortars and one 5"/38 dual purpose gun mounts.) Photo by John A. McDonald USS LSMR-524. Mark McDonald for his father John A. McDonald S1/c USS LSM(R)-524
    LSMR-524 80k USS LSM(R)-524 (left) and USS LSM(R)-525 (right) preparing to get underway, probably from Southern Pacific Docks, Houston, TX. for NAB Little Creek, VA., circa August 1945. Photo by John A. McDonald USS LSMR-524. Mark McDonald for his father John A. McDonald S1/c USS LSM(R)-524
    LSMR-524 81k USS LSM(R)-524's 5"/38 gun mount and conning tower. Note camouflage paint. Photo by John A. McDonald USS LSMR-524. Mark McDonald for his father John A. McDonald S1/c USS LSM(R)-524
    LSMR-524 94k USS LSM(R)-524's starboard diesel engine. Photo by John A. McDonald USS LSMR-524. Mark McDonald for his father John A. McDonald S1/c USS LSM(R)-524
    LSMR-524 29k USS LSM(R)-524 moored pierside at US Atlantic Fleet Amphibious Base Little Creek, Norfolk, VA. - crew finishing camouflage painting on the port side, circa 1945. Photo by John A. McDonald USS LSMR-524. Mark McDonald for his father John A. McDonald S1/c USS LSM(R)-524
    LSMR-524 28k USS LSM(R)-524 moored pierside with USS LSM(R) 525 or USS LSM(R)-523 at the US Atlantic Fleet Amphibious Base Little Creek Norfolk VA in 1945. Mark McDonald for his father John A. McDonald S1/c USS LSM(R)-524
    LSMR-524 49k USS LSM(R)-524 underway, enroute to Florida, date unknown. Mark McDonald for his father John A. McDonald S1/c USS LSM(R)-524
    LSMR-524 87k USS LSM(R)-524 gunnery crew in action firing one of the ship's twin 20 mm guns during a practice drill, date and location unknown. Photo by John A. McDonald USS LSMR-524. Mark McDonald for his father John A. McDonald S1/c USS LSM(R)-524
    LSMR-524 82k USS LSM(R)-524 gunnery crew firing one of the ship's twin 20 mm guns during a practice drill, date and location unknown. Photo by John A. McDonald USS LSMR-524. Mark McDonald for his father John A. McDonald S1/c USS LSM(R)-524
    LSMR-524 71k USS LSM(R)-524 gunnery crew firing one of the ship's twin 20 mm guns during a practice drill, date and location unknown. Photo by John A. McDonald USS LSMR-524. Mark McDonald for his father John A. McDonald S1/c USS LSM(R)-524
    LSMR-524 91k USS LSM(R)-524 gunnery crew firing the bow twin 40mm guns during a practice drill, date and location unknown. Photo by Vernice R. Thompson. Mark McDonald for his father John A. McDonald S1/c USS LSM(R)-524
    LSMR-524 78k USS LSM(R)-524 gunnery crew firing the stern twin 40mm guns during a practice drill, date and location unknown. Photo by John A,. McDonald. Mark McDonald for his father John A. McDonald S1/c USS LSM(R)-524
    LSMR-524 63k USS LSM(R)-524 firing its 5" SS Rockets off the starboard side during a live fire exercise, date and location unknown. Photo by John A. McDonald. Mark McDonald for his father John A. McDonald S1/c USS LSM(R)-524
    LSMR-524 30k USS LSM(R)-524 firing its 5" SS Rockets off the port side during a practice drill, date and location unknown. Photo by John A. McDonald. Mark McDonald for his father John A. McDonald S1/c USS LSM(R)-524
    LSMR-524 57k USS LSM(R)-524 gunnery crew firing its stern twin 40mm gun during a practice drill - picture taken from the conning station - date and location unknown. Photo by John A. McDonald. Mark McDonald for his father John A. McDonald S1/c USS LSM(R)-524
    LSMR-524 55k USS LSM(R)-524 was at GQ during a live fire exercise, 5 October 1945, in area North Charlie, Chesapeake Bay, when the twin 40mm gun crew shot down this drone aircraft. Photo by John A. McDonald. Mark McDonald for his father John A. McDonald S1/c USS LSM(R)-524
    LSMR-524 60k USS LSM(R)-524 under way in the Chesapeake Bay, date unknown. After securing from GQ crew observes object floating in the water. Possibly a target or weather balloon. Photo by John A. McDonald. Mark McDonald for his father John A. McDonald S1/c USS LSM(R)-524
    LSMR-524 59k Night scene looking out over USS LSM(R)-524's 5"/38 gun mount while the ship is moored, date and location unknown. Photo by John A. McDonald. Mark McDonald for his father John A. McDonald S1/c USS LSM(R)-524
    LSMR-524 54k USS LSM(R)-524 launch coming alongside, date and location unknown. Photo by John A. McDonald. Mark McDonald for his father John A. McDonald S1/c USS LSM(R)-524
    LSMR-524 73k USS LSM(R)-524 anchored at Green Cove Springs, FL.. Note; crew members on the scaffold repainting the ship's port side for the decommissioning stage on 21 May 1946. Note; crew members on the scaffold painting the ship's port side. Photo by John A. McDonald USS LSMR-524. Robert Jackson USS LSM(R)-524, courtesy, Mark McDonald for his father John A. McDonald S1/c USS LSM(R)-524
    LSMR-524 46k Close-up of above photo - USS LSM(R)-524 anchored at Green Cove Springs, FL. prior to decommissioning. Photo by John A. McDonald USS LSM(R)-524. Robert Jackson USS LSM(R)-524, courtesy, Mark McDonald for his father John A. McDonald S1/c USS LSM(R)-524
    LSMR-523 95k USS LSM(R)-523,
    LSM(R)-524,
    USS LSM(R)-525,
    USS LSM(R)-527,
    USS LSM(R)-526 and
    USS LSM(R)-519
    at anchor in a nest of six LSMRs at Green Cove Springs, FL, January 1946. The deck log entry of USS LSM(R)-524 for January 1946 indicates the following:
    "Moored at Berth Oak 31, St. John's River, Green Cove Springs, Fla. in 14 feet of water, mud bottom, with 35 fathoms of chain to bow anchor, 300 feet of cable to the stern anchor and moored port side to the USS LSM(R) 523 moored to the starboard side, the starboard side to the USS LSM (R) 525 moored to the port, port side to, USS LSM (R) 527 moored to the USS LSM (R) 525, USS LSM (R) 526 moored to LSM (R) 527, USS LSM (R) 519 moored to starboard side of USS LSM (R) 526 on the following Bridge bearing 166 (T), North End of bridge 068 (T), tower 219 (T) with the following machinery in operation #1 ship service generator, #1 boiler, #2 refrigerator, #2 fresh water pump, #2 fire and flushing pump, #2 air compressor"
    Photo submitted by Donald Tourville USS LSMR-528
    Log Entry submitted by Mark McDonald for his father John A. McDonald S1/c USS LSM(R)-524
    Pit River 58k Seventeen LSM(R)s at Green Cove Springs, FL. during Operation "Zipper", the process of decommissioning the fleet, commonly called "mothballing", March 1946.
    From front to back:
    USS LSM(R)-519
    USS LSM(R)-526,
    USS LSM(R)-527,
    USS LSM(R)-525,
    USS LSM(R)-524, (See Deck Log entry below)
    USS LSM(R)-529,
    USS LSM(R)-521,
    USS LSM(R)-528,
    USS LSM(R)-522,
    USS LSM(R)-531,
    USS LSM(R)-536,
    USS LSM(R)-535,
    USS LSM(R)-534,
    USS LSM(R)-520,
    USS LSM(R)-533,
    USS LSM(R)-530,
    USS LSM(R)-523,
    The USS LSM(R)-524 Deck Log states during the month of March 1946
    Moored in Birth Oak 31, St. Johns River Green Cove Springs. Fla. Anchorage in 14 feet of water, mud bottom with 65 fathoms of chain to bow anchor and 495 feet of cable to the stern anchor. Nested with LSM (R) type ships: 523, 530, 533, 520, 534, 535, 536, 531, 522, 528, 521, and 529, moored to our starboard numbering from inboard to outboard. LSM(R) type ships: 525, 527, 526, and 519, moored to our port numbering from inboard to outboard , on the following bearing: bridge opening 180 .5 (T), signal tower 235 (T), pt. of land 336 (T). The following machinery in operation: #1 generator, #1 evaporator, #2 fire & flushing pumps, #2 fresh water pumps, #2 refrigeration unit.
    Robert Hanle to the USS LSM / LSMR Association
    Log Entry submitted by Mark McDonald for his father John A. McDonald S1/c USS LSM(R)-524
    LSMR-524 640k Painting of USS LSM(R)-524 by Dr. Bernard John Heetderks Jr.. Dr. Heetderks was a S1/c and he worked in Fire Control on the 524. Mark McDonald
    USS LSM(R)-524 Model
    LSMR-524 611k The solid mahogany model of USS LSM(R)-524 was built by Motion Models of Florida. It is 30" in length and 13" high at the top of the conning tower mast. The model is authentically detailed with the proper armament and pre-invasion camouflage color scheme for that era. The model, commissioned by Mark McDonald, was made in loving memory of his father, John A McDonald S1/c, and his ship mates who served in USS LSM(R)-524. At this time in history the crew was preparing for Operation Olympic. The first stage of Operation Downfall, the invasion of the southern most main Japanese Island of Kyushu. Photos by Mark McDonald
    LSMR-524 910k
    LSMR-524 LSMR-524 LSMR-524 LSMR-524 LSMR-524 LSMR-524
    LSMR-524 LSMR-524 LSMR-524 LSMR-524 LSMR-524 LSMR-524

    USS LSM(R)-524 / USS St Croix River (LSMR-524)
